DS-7700NI-SP/9000/9600 Series HDVR/NVR User’s Manual
116
3. Select the Mode to Quota.
4. Select a camera for which you want to configure quota.
5. Enter the storage capacity in the text fields of Max. Record Capacity (GB) and Max. Picture
Capacity (GB).
6. If the same settings can be applied in other channels, click Copy.
7. Click the Apply button to save the settings.
Note:
If the quota capacity is set to 0, then all cameras will use the total capacity of HDD for record and picture
capture.
Managing HDD Group
Multiple HDDs can be managed in groups. Video from specified channels can be recorded onto a
particular HDD group through HDD settings. To managing HDD Group:
1. Enter the HDD menu by going to Menu > System Configuration > HDD.
2. Select the Storage Mode tab, as shown in Figure 130.
3. Select the Mode to Group, as show in Figure 131.
Figure 131 Group Mode Settings Menu
4. Click the Apply button to pop up an attention box as shown below:
Figure 132 Attention for reboot
5. Click Yes to reboot and make the settings effective. Click No to cancel the operation.
6. After rebooting, you can configure local HDD settings. To configure local HDD settings by going
to Menu > System Configuration > HDD > HDD Information.
1) Select a HDD and click to pop up the Local HDD Settings menu as shown in Figure
133.
