HIKVISION DS-C30S-S23 User Manual

Video Wall Controller • User Manual
10

For an output board with four HDMI ports or four DVI ports, the loading capacity of each port
cannot exceed 2.6 MP.

For an output board with two HDMI ports, the loading capacity of each port cannot exceed 8.8
MP.

When an HDMI output port is configured with DVI mode, its loading capacity cannot exceed
2.3 MP.
(Optional) Click Copy To to copy the current configuration to other selected output ports.
Click Save.
Configure Output Port
(Optional) You can perform the following operations as required:

HIKVISION DS-C30S-S23 Specifications

General

Product color	Black
Rack capacity	8U
Built-in display	Yes
Housing material	Metal
Input voltage	100 - 240 V
Input frequency	50/60 Hz
Power consumption (max)	1000 W
Ethernet LAN data rates	10, 100, 1000 Mbit/s
RJ-45 ports quantity	2
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	447 mm
Width	442 mm
Height	354.8 mm
