UM IPC-4300H 040320NA 150

If is not pressed to shut off the lamp and to exit the

application, the lamp will stay on. Click the Time Setting button to

set a timer that will shut off the lamp.

2.3.38. Browser

Click to open.

Type in the camera’s IP address and press Go to access the IP

camera’s interface.

Live video cannot be viewed in the Web browser. To view

video, use the IP Tester‘s live camera view applications.

Figure 154, IP Camera Browser Screen
