Box Contents

• Tester

• 12 VDC/2A adapter

• Network cable Tester

• Polymer lithium ion battery (7.4 VDC/5000 mAh)

• BNC cable

• RS-485 cable

• SC, ST connector (only for optical power meter)

• Output power cable

• Audio cable

• TDR alligator clamp (only for TDR Models)

• Safety cord

• Tool bag

• Manual

• 8 GB SD card
