UM IPC-4300H 040320NA 25

Figure 3, Voltage Lead Setup

Instrument Connection

2.2.1. IP Camera Connection

Connect the IP camera to an independent power supply and connect

the IP camera to the Tester’s LAN port.

If the link indicator next to the Tester’s LAN port is green and the

data indicator flickers, the IP camera and the Tester are

communicating.

If the two indicators do not flicker, check if the IP camera is powered

on or if the network cable is functioning properly.
