UM IPC-4300H 040320NA 4

2006/66/EC (Battery Directive): This product contains a battery that cannot

be disposed of as unsorted municipal waste in the European Union. See the

product documentation for specific battery information. The battery is

marked with this symbol, which may include lettering to indicate cadmium

(Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your

supplier or to a designated collection point. For more information see: www.recyclethis.info

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.
