UM IPC-4300H 040320NA 175
DC Current
Range
Accuracy
Resolution
6.600 mA
± (0.5%+3)
1 µA
66.00 mA
10 µA
660.0 mA
100 µA
10.00 A
± (1%+5)
10 mA
AC Current
Range
Accuracy
Resolution
6.600 mA
± (0.5%+3)
1 µA
66.00 mA
10 µA
660.0 mA
100 µA
10.00 A
± (1%+5)
10 mA
Resistance
Range
Accuracy
Resolution
660.0 Ω
± (0.8%+5)
0.1 Ω
6.600 kΩ
± (0.8%+2)
1 Ω
66.00 kΩ
10 Ω
660.0 kΩ
100 Ω
6.600 MΩ
1 kΩ
66 mΩ
± (1.2%+5)
10 kΩ
Continuity
Range
Resolution
Function
660.0 Ω
0.1 Ω
The Tester will sound if it detects
values lower than 30 Ω±3 Ω.
