Table 2, Top Interface Functions

RS-485 Interface: RS-485 communication for PTZ

RS-232 Interface: RS-232 communication for PTZ “HD In”,
AHD/TVI/CVI coaxial interface (Optional)

12 VDC/2A power output for provisional DC power supply

TDR cable test interface

LED lamp

SDI input (BNC interface) (Optional)

HDMI input

Video image signal output (BNC interface)/cable tracer
interface (Optional)

Video image signal output (BNC interface)/AHD, CVI and
TVI input (BNC interface) (Optional)

Optical power meter interface (Optional)

Visible red laser source emitter interface (Optional)

UTP cable port: UTP cable Tester port/cable tracer port

Removable 8 GB microSD card, up to 32 GB available

Audio input

HDMI output interface

Audi and headphone output

5 VDC/2A USB power output (power bank)

12 VDC/2A charging interface

PSE power sourcing equipment. Tests PoE voltage.

PoE power supply output or LAN test port (used to test
PoE or non-PoE IP cameras)
