Figure 71, SDI Tester - Resolution

The IP Camera Tester’s HDMI output port can be used as an SDI-to-

HDMI converter, i.e. to output HD SDI images to an HD TV monitor.

Select relative function on the right side of the toolbar for the

following options: Snapshot, Record, Photos, Video Playback, PTZ

Control, Video Brightness and Storage Set.

The operation is the same as for the video monitor function.

Please refer to the Section 2.3.10: Video Monitor Test for more

details.

Click or press

to quit.
