Function Checks
Chapter 2: Troubleshooting Procedures
Yes No
y —> Replace the access door (1) gasket.
11. Check that the inner walls are properly latched. Open the access panel(s)
(F). The front and rear inner walls are properly latched.
Yes No
y -5 Replace the inner wall.
12. Check the mattress (L) elevators. Rotate the right mattress tilt mechanism
knob (K) counterclockwise until it stops. The right end of the mattress (L)
is at a 12° angle.
Yes No
y — Replace the mattress elevator.
13. Rotate the right mattress tilt mechanism knob (K) clockwise until it stops.
The mattress (L) is level.
Yes No
y —> Replace the mattress elevator.
14. Turn the left mattress tilt mechanism knob (K) clockwise. The left end of
the mattress (L) is at a 12° angle.
Yes No
y > Replace the mattress elevator.
15. Turn the left mattress tilt mechanism knob (K) counterclockwise. The
mattress (L) is level.
Yes No
y —> Replace the mattress elevator.
16. Check the mattress tray (M) operation.
Slide out the mattress tray (M) to the fully-extended position.
b. Carefully lean on the mattress tray (M) to make sure it is properly
supported to provide a firm infant platform.
c. Return the mattress (L), and close the access panel (F).
The mattress tray (M) is a firm platform for an infant.
Yes No
小 —> Replace the mattress tray (M).
17. Check the air intake microfilter (N) (see figure 2-3 on page 2-10).
Isolette® Infant Incubator Service Manual (man223rf) Page 2-9
