Chapter 3 Measurement Procedures
――――――――――――――――――――――――
NOTE
3.2.2 DC Voltage Measurement
(1) Set the rotary switch to "
/ V ".
(2) Push
SHIFT
button momentarily to set DC test.
(3) Connect the black test lead to "COM" terminal
and red test lead to "
" terminal.
(4) Touch the test leads to the test points and read
the display.
The display value may sometimes fluctuate even
when the multimeter is not switched on. This is due
to induced voltage, and is not a malfunction.
