Chapter 3 Measurement Procedures
――――――――――――――――――――――――
DANGER
Never apply voltage to the test leads when the
Resistance, Continuity Check functions are
selected. Doing so may damage the product
and result in personal injury.
To avoid electrical accidents, remove power
from the circuit before measuring.
3.4 Resistance Measurement
(1) Set the rotary switch to " ".
(2) Connect the black test lead to "COM" terminal
and red test lead to "
" terminal.
(3) Touch the test leads to resistor and read the
display.
(4) Press
SHIFT
button momentarily to toggle
CONTINUITY function ON/OFF. The
continuity range is 0 to 400.0 Ω.
(5) Momentarily pushing this button will only turn
the beeper off. While testing continuity, the
beeper will sound if the resistance falls below
345 counts. And it will stop if the resistance
exceeds 350 counts.
