Hioki 3803 - AC Current Measurement

20
―――――――――――――――――――――――――――
Chapter 3 Measurement Procedures
――――――――――――――――――――――――
NOTE
Instrument operated by
alternatin
g
current
3.5.1 AC Current Measu rement
(1) Set the rotary switch to "
/ A ".
(2) Connect the black test lead to "COM" terminal
and red test lead to "A" terminal.
(3) Touch the test leads to the test points and read
the display.
If the reading is lower than 400 mA, to get better
resolution of display, please turn the rotary switch to
mA or μA position and remove the red test lead to
"μAmA" terminal.
