Hioki 3803 - Page 93

35
―――――――――――――――――――――――――――
Chapter 5 Specifications
――――――――――――――――――――――――
Range
Resolut
-ion
Accuracy
Maximum
Test
Voltage
Overload
Protection
400.0 Ω 0.1 Ω
0.6%rdg. 3dgt.
1.2 V
max.
600 V DC/
600 V rms
4.000 kΩ 1 Ω
40.00 kΩ 10 Ω
0.45 V
max.
400.0 kΩ 100 Ω
4.000 MΩ 1kΩ 1.2%rdg. 3dgt.
40.00 MΩ 10 kΩ 2%rdg. 3dgt.
Range Threshold Level
Overload
Protection
400.0Ω
The beeper will sound if the
resistance falls below 34.5 Ω.
And it will stop if the resistance
exceeds 35.0 Ω.
600 V DC/
600 V rms
Range
Resolution
Accuracy
Test Current
Voltage
Overload
Protection
1.999 V
1mV
1.0%rdg. 2dgt.
approx. 1.65 mA
Less than 3 V
600 V DC/
600 V rms
(5) RESISTANCE
(6) AUDIBLE CONTINUITY TEST
The measurement accuracy and open terminal voltage (test voltage)
are the same as these of Ω function.
(7) DIODE CHECK
