38
―――――――――――――――――――――――――――
Chapter 6 Maintenance and Service
――――――――――――――――――――――――
Use the following procedures to replace the battery,
or fuse.
(1) Using the rotary switch to turn the meter off,
and remove the test leads from terminals.
(2) Loosen 3 screws on bottom cover, pull up and
move the cover.
(3) Replace the defective battery.
The meter is powered by a 6F22 battery. Replace
battery if the low battery sign (
) is displayed
and flashes.
(4) Remove the defective fuse by gently prying one
end of the fuse loose and sliding the fuse out of
the fuse bracket.
Install a new fuse of the same size and rating.
Make sure the new fuse is centered in the fuse
holder. There are 2 types of fuses, one for the
μA , mA terminal and one for the A terminal.
Be sure to set the correct fuse.
(5) Reverse the procedure of opening cover to close
the bottom cover.
