Specications of Input, Output, and Measurement
External interface specications
(1) USB ash drive
Connector USB Type A receptacle connector
×
1
Standard/method USB 3.0 (Super Speed)
Device to be
connected
USB ash drive
Data to be recorded
on USB ash drives
Saving/loading settings les
Saving measurement values and automatically recorded data
Saving waveform data and screenshots
(2) LAN
Connector RJ-45 connector
×
1
Standard/method IEEE 802.3 compliant
Transmission
method
100Base-TX, 1000Base-T (automatic detection)
Protocol TCP/IP (with DHCP function)
Functions HTTP server (remote operation)
Dedicated port (data transfer, command control)
FTP server (le transfer)
FTP client
(3) GP-IB
Connector Micro-ribbon 24-pin connector
×
1
Standard/method In conformity with IEEE-488.1 1987, in consultation with IEEE-488.2 1987
Addresses 00 to 30
Remote control The REMOTE/LOCAL key is lit up while the instrument is in remote mode. Pressing the
REMOTE/LOCAL key allows the instrument exit remote mode.
(4) RS-232C
Connector D-sub 9-pin connector
×
1, 9 pins, shared with the external control
Standard/method RS-232C, in conformity with EIA RS-232D, CCITT V.24, and JIS X5101
Full duplex, start-stop synchronization, data length: 8, no parity, stop bit: 1
Flow control Not equipped
Communications
speed
9600 bps, 19200 bps, 38400 bps, 57600 bps, 115200 bps
Function Switchable between command control and external control (simultaneous use not
supported)
(5) External control
Connector D-sub 9-pin connector
×
1, commonly used with RS-232C
Pin assignment No. 1 pin: Start/stop
No. 4 pin: Hold (event)
No. 5 pin: Ground
No. 6 pin: Data reset
Electrical
specications
Tow-level (low: 0 V, high: 2.5 V to 5 V) logic signals or contact signal with terminal shorted/
open
Function Same operation as the START/STOP key, DATA RESET key, or HOLD key on the control
panel
Switchable with RS-232C (simultaneous use not supported)
