243
Rackmount Fittings
Blank panel for a JIS-compliant rack
Material: A5052
Thickness: t1.6
431.6
27.6
427.4
23.6
5
15
2×C3
(1.6 )
(Unit: mm)
M3 press nut
M3 press nut
EIA-compliant rackmount tting
Material: A5052
Thickness: t3
C
L
27
80
15.6
2×C2
C
L
101.6
221.5
25.3
8.8
R3.5
6×C2
7
(3)
(Unit: mm)
2
×
M5 spacer (reference: Fabace FK-M5-6)
Maintenance and Service
