42
Target voltage 250V
Displayed value
1.25 6.25 12.5
Output voltage
1V 5V 10V
Target voltage 500V
Displayed value
2.5 12.5 25
Output voltage
1V 5V 10V
Target voltage 1000V
Displayed value
5 25 50
Output voltage
1V 5V 10V
Example
・ SM-8220
Target voltage : 500V
RANGE : ×10
5
Measurement range : 2.5×10
5
MΩ to 100×10
5
MΩ
・ Output voltage of RP-8000
Output range : 2.5×10
5
MΩ to 25×10
5
MΩ
Output voltage : 1V/2.5×10
5
MΩ , 10V/25×10
5
MΩ
9.1.2 DC Output, RI-8000 – 1/R or inversely proportional to resistance
In insulation resistance, as described in 9.1.1 DC Output, RP-8000, if the
measuring voltage is constant, the current flowing through the sample is
halved, and the output voltage is also halved when the insulation
resistance -- R -- is doubled. This relation can be expressed as “1/R.”
The RI-8000 provides this type of DC signal output.
1) Specifications
Output Range: Full range of the measuring range of the SM-8200
Series super megohmmeter
Output Voltage: 10V/minimum value , 1 V/10 times minimum value
Output Accuracy: Within 10% of displayed value in the range from
minimum value to 10 times minimum value
2) Usage
Measure the insulation resistance of a sample with the method
designed in 6.1 Measuring Method. There is no limitation in the
applications in relation with the provision of the RI-8000 DC output.
Fig. 9.1.1 on the previous page shows the DC OUT (OPTION) “G”/”+”
terminals on the external input/output terminal block on the rear of
the unit.
