Network Load Control
Basic Configuration
Release
6.0
07/2010
8.1
Direct Packet Distribution
123
8.1.5 Disabling the Direct Packet Distribution
To enable you to observe the data at all the ports, the device allows you to
disable the learning of addresses. When the learning of addresses is
disabled, the device transfers all the data from all ports to all ports.
Select the
Switching:Filters for MAC Addresses dialog.
Each row of the filter table represents one filter. Filters specify the way
in which data packets are sent. They are set automatically by the Switch
(learned status) or created manually. Data packets whose destination
address is entered in the table are sent from the receiving port to the
ports marked in the table. Data packets whose destination address is
not in the table are sent from the receiving port to all other ports. In the
"Create filter" dialog you can set up new filters. The following status
settings are possible:
X learned: The filter was created automatically by the device.
X invalid: With this status you delete a manually created filter.
X permanent: The filter is stored permanently in the device or on the
URL (see on page 59 “Saving settings“).
X gmrp: The filter was created by GMRP.
X gmrp/permanent: GMRP added further port markings to the filter
after it was created by the administrator. The port markings added
by the GMRP are deleted by a restart.
X igmp: The filter was created by IGMP Snooping.
To delete entries with the "learned" status from the filter table, select the
Basics:Restart dialog and click "Reset MAC address table".
