Access to the user interfaces
16
1.1
System Monitor
Basic Configuration
Release
6.0
07/2010
1.1 System Monitor
The system monitor enables you to
X select the software to be loaded
X perform a software update
X start the selected software
X shut down the system monitor
X delete the configuration saved and
X display the boot code information.
Opening the system monitor
Use the terminal cable (see accessories) to connect
– the V.24 socket (RJ11) to
– a terminal or a COM port of a PC with terminal emulation based on
VT100
(for the physical connection, see the "Installation" user manual).
Start the terminal program on the PC and set up a connection with the
device.
When you boot the device, the message
"Press <1> to enter System Monitor 1"
appears on the terminal.
Speed 9,600 Baud
Data 8 bit
Parity none
Stopbit 1 bit
Handshake off
Table 1: Data transfer parameters
