Operation Diagnosis
196
9.6
Displaying the SFP Status
Basic Config
uration
Release
6.0
07/2010
9.6
Displaying the SFP Sta
tus
The SFP status display allows you to
look at the current SFP module
connections and their properti
es. The propert
ies include:
X
module type
X
support provided in media module
X
Temperature in ºC
X
Tx Power in mW
X
Receive power in mW
Select the
Diagnostics:Ports:SFP Modules
dialog.
Figure 55:
SFP
Modules dialog
195
197
