Page #287 background imageLoading...
Page #287 background image
MACH 100
Release
07/09
35
3 Technical data
General technical data
EMC and immunity
Dimensions
W x H x D
MACH 102-... 448 mm x 310 mm x 44 mm (without brackets)
Weight of devices MACH102-
8TPMACH102-8TP-
RMACH102-8TP-
FMACH102-8TP-
FRMACH102-24TP-
FMACH102-24TP-FR
3.60 kg
3.85 kg
3.60 kg
3.85 kg
3.85 kg
4.10 kg
Weight of
media modules
M1-8TP-RJ45M1-
8MM-SCM1-8SM-
SCM1-8SFP
0.21 kg
0.21 kg
0.18 kg
0.13 kg
Power supply Rated voltage
Rated frequency
Rated power range
100 - 240 VAC
47 - 63 Hz
0.4 - 0.2 A
Overload current
protection at input
Non-replaceable fuse
Activation current typ. <40 A at 265 V AC and cold start
“FAULT”
signal contact
max. 60 V DC or max. 30 V AC, SELV
Environment Storage temperature
(ambient air tempera-
ture)
Humidity
Air pressure (in opera-
tion)
-20 °C to +85 °C
10% to 95% (non-condensing)
Up to 2000 m (795 hPa), higher altitudes on
request
Operating temper-
ature
0 °C to +50 °C
Pollution degree 2
Protection classes Laser protection
Protection class
Class 1 according to EN 60825-1 (2001)
IP 20
EMC interference
immunity
EN 61000-4-2 Electrostatic discharge
Contact discharge
Air discharge
4 kV
8 kV
EN 61000-4-3 Electromagnetic field
80 - 2,700 MHz 10 V/m
EN 61000-4-4 Fast transients (burst)
- Power line
- Data line
2 kV
4 kV
