Hirschmann MACH1000 Series User Manual

Installation MACH1000
Release 06 03/2021
19
11 ... 12 10/100 Mbit/s ports 1 + 2
a
99 Module position empty
TT 2 × Twisted pair TX, RJ45, 10/100 Mbit/s
BB 2 × Multimode FX LC, 100 Mbit/s
MM 2 × Multimode FX DSC, 100 Mbit/s
JJ 2 × Multimode FX MTRJ, 100 Mbit/s
NN 2 × Multimode FX ST, 100 Mbit/s
VV 2 × Singlemode FX DSC, 100 Mbit/s
UU 2 × Singlemode FX ST, 100 Mbit/s
LL 2 × Singlemode Long Haul FX DSC,
100 Mbit/s
GG 2 × Singlemode Long Haul FX DSC,
124.27 mi (200 km), 100 Mbit/s
ZZ 2 × SFP slot, 100 Mbit/s
RR 2 × Twisted pair TX, RJ45, 10/100 Mbit/s
FF
b
2 × Multimode FL ST, 10 Mbit/s
13 ... 14 10/100 Mbit/s ports 3 + 4 See 11 ... 12
15 ... 16 10/100 Mbit/s ports 5 + 6 See 11 ... 12
17 ... 18 10/100 Mbit/s ports 7 + 8 See 11 ... 12
19 ... 20 10/100 Mbit/s ports 9 + 10 See 11 ... 12
21 ... 22 10/100 Mbit/s ports 11 + 12 See 11 ... 12
23 ... 24 10/100 Mbit/s ports 13 + 14 See 11 ... 12
25 ... 26 10/100 Mbit/s ports 15 + 16 See 11 ... 12
27 ... 28 10/100 Mbit/s ports 17 + 18 See 11 ... 12
29 ... 30 10/100 Mbit/s ports 19 + 20 See 11 ... 12
31 ... 32 10/100 Mbit/s ports 21 + 22 See 11 ... 12
33 ... 34 10/100 Mbit/s ports 23 + 24 See 11 ... 12
35 Temperature range S Standard
U Extended
F Extended, Conformal Coating
36 Characteristic value power
supply unit 1
C
G
L
M
Specification of the supply voltage
characteristic value
37 Characteristic value of
power supply unit 2
9 Not present
C
G
L
M
Specification of the supply voltage
characteristic value
38 Approvals H CE, UL 508, ISA 12.12.01- Class I, Div. 2,
GL, IEC 61850, IEEE 1613 Substation,
EN 50121-4 Railway (along track),
NEMA TS2
T CE, UL 508, ISA 12.12.01- Class I, Div. 2,
EN 50121-4 Railway (along track),
NEMA TS2, EN 50155 Railway (train)
cd
39 Software variant P Professional
Position Characteristic Characteris-
tic value
Property
Table 1: Combination options for the device variants of MACH1000
