54
Installation MACH1000
Release
06
03/2021
7 Technical data
General technical data
Dimensions
W × H × D
Devices with terminal
connection voltage supply
(power supply unit
characteristic value C
and G)
448 × 310 × 44 mm
(without brackets)
Devices with pluggable
voltage supply
(power supply unit
characteristic value T
and M)
448 × 345 × 44 mm
(without brackets)
Weight (incl.
redundant power
supply or PoE power
supply)
MAR1020-... fully equipped max. 4.6 kg
MAR1030-... fully equipped max. 4.7 kg
MAR1120-... fully equipped
(incl. redundant power unit)
max. 5.4 kg
MAR1130-... fully equipped
(incl. redundant power unit)
max. 5.5 kg
MAR1122-... fully equipped max. 5.5 kg
MAR1132-... fully equipped max. 5.6 kg
MAR1022-... fully equipped max. 4.7 kg
MAR1032-... fully equipped max. 4.8 kg
Weight MAR1020-... basic device approx. 3.9 kg
MAR1030-... basic device approx. 4.0 kg
MAR1120-... basic device approx. 4.7 kg
MAR1130-... basic device approx. 4.8 kg
MAR1122-... basic device approx. 5.1 kg
MAR1132-... basic device approx. 5.2 kg
MAR1022-... basic device approx. 4.3 kg
MAR1032-... basic device approx. 4.4 kg
Optional PoE power unit approx. 0.3 kg
Optional second power unit additional approx. 0.3 kg
Per 6 ports (3 modules) additional approx. 0.1 kg
Per M12 module additional approx. 0.09 kg
Power supply
characteristic value G
and M
Rated voltage range 100 V AC ... 240 V AC, 50 Hz ...60 Hz
110 V DC ... 250 V DC
Devices with certification characteristic
valueT: 110V
Voltage range including
maximum tolerances
90 V AC ... 265 V AC, 47 Hz ... 63 Hz
77 V DC ... 300 V DC
Connection supply voltage
characteristic value G
3-pin spring-loaded terminal for copper
wire with cross-section AWG20 ... AWG12
(0.5 mm² ... 3.0 mm²) and stripping length
12 mm
Connection supply voltage
characteristic value M
3-pin terminal block
Power loss buffer > 20 ms at 230 V AC
Peak inrush current 14 A
