Hirschmann MACH1000 Series User Manual

Installation MACH1000
Release 06 03/2021
33
1.5 Display elements
After the supply voltage is set up, the software starts and initializes itself.
Afterwards, the device performs a self-test. During this process, various
LEDs light up. The process takes around 60 seconds.
Figure 8: Display elements MACH1000, device variants with ports in front
1 - Display elements device status
2 - Display elements port status
Figure 9: Display elements MACH1000, device variants with ports at the back
1 - Display elements device status
2 - Display elements port status for up to 4 × Gigabit Ethernet ports and
up to 20 × Fast Ethernet ports
3 - Diagnostic port with display element
USB
V.24
MACH 1000
P
StandByRM
FAULT
R1
R2
1
2
P
StandByRM
FAULT
R1
R2
ETHERNET Service Port
1
3
5
7
9
11
13
15
17
19
21
23
2
4
6
8
10
12
14
16
18
20
22
24
21 3
