18
Installation MACH1000
Release
06
03/2021
1.2 Combination options
The product designation of your device is made from combining the desired
product characteristics in accordance with the following table. The
corresponding short designation is in column 3.
You have numerous options of combining the device characteristics. You can
determine the possible combinations using the configurator which is
available in the Belden Online Catalog https://catalog.belden.com on the web
page of the device.
Position Characteristic Characteris-
tic value
Property
1 ... 7 Product MAR1020 MACH Ruggedized Fast Ethernet Switch
MAR1030 MACH Ruggedized Gigabit Ethernet
Switch
MAR1022 MACH Ruggedized Fast Ethernet Switch
with PoE
ab
MAR1032 MACH Ruggedized Gigabit Ethernet
Switch with PoE
ab
MAR1120 MACH Ruggedized Fast Ethernet Switch,
ports on the back
MAR1130 MACH Ruggedized Gigabit Ethernet
Switch, ports on the back
MAR1122 MACH Ruggedized Fast Ethernet Switch,
ports on the back and with PoE
ab
MAR1132 MACH Ruggedized Gigabit Ethernet
Switch, ports on the back and with PoE
ab
8 - (hyphen) -
9 ... 10 10/100/1000 Mbit/s ports
1 + 2 or 1 ... 4
99 Not present (in MAR1020)
CC 2 × Combo port (SFP slot: 100/
1000 Mbit/s, alternatively twisted pair
RJ45 socket: 10/100/1000 Mbit/s)
4O 2 × 2 Gigabit Ethernet ports SFP slot
1000 Mbit/s
4T 2 × 2 Gigabit Ethernet ports RJ45 10/100/
1000 Mbit/s
OT 2 × Gigabit Ethernet port SFP slot
1000 Mbit/s plus 2 × Gigabit Ethernet port
RJ45 10/100/1000 Mbit/s
Table 1: Combination options for the device variants of MACH1000
