40
Installation MACH1000
Release
06
03/2021
Proceed as follows:
Take the SFP transceiver out of the transport packaging (1).
Remove the protection cap from the SFP transceiver (2).
Push the SFP transceiver with the lock closed into the slot until it latches
in (3).
2.3 Connecting the power unit connections for
supply voltage and signal contact
2.3.1 Connecting the voltage supply terminals (power
supply unit characteristic value C and G)
Note: Note the permitted voltage ranges for devices with
certification characteristic value T (EN 50155 railway (train) - see
product code position 38 in table 1).
Figure 12: Power supply unit characteristic value C, DC voltage (“General technical
data” on page 54)
Connecting
1 - Supply voltage
2 - Signal contact
WARNING
ELECTRIC SHOCK
Connect only a supply voltage that corresponds to the type plate of your
device.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
