Hirschmann MACH1000 Series User Manual

48
Installation MACH1000
Release 06 03/2021
2.4.2 Vertical mounting on the wall
 Move the two pre-installed mounting brackets into the position shown
below.
 Additionally attach 2 brackets to the back of the device.
You obtain the additional brackets as accessories.
See “Accessories” on page 65.
 Fasten the device by screwing the brackets to the wall.
2.4.3 Grounding the device
The device is grounded via the separate grounding screw on the back of the
device.
WARNING
FIRE HAZARD
Install the device in a fire enclosure according to EN 62368-1 if you install
the device vertically.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
