Installation MACH1000
Release
06
03/2021
55
Power supply
characteristic value C
and L
Rated voltage range 24 V DC ... 48 V DC
Devices with certification characteristic
value T: 36 V
Voltage range incl.
maximum tolerances
18 V DC ... 60 V DC
Connection supply voltage
characteristic value C
3-pin spring-loaded terminal for copper
wire with cross-section AWG20 ... AWG12
(0.5 mm² ... 3.0 mm²) and stripping length
12 mm
Connection supply voltage
characteristic value L
3-pin terminal block
Power loss buffer > 10 ms at 20.4 V DC
Peak inrush current 15 A
Input voltage for
device variants with
PoE
Rated voltage range 110 V DC ... 250 V DC
110 V AC ... 230 V AC
Voltage range incl.
maximum tolerances
77 V DC ... 300 V DC
90 V AC ... 265 V AC, 47 Hz ... 63 Hz
Output voltage for
device variants with
PoE
48 V DC ± 5%
Back-up fuse Supply voltage
characteristic value C and L
Nominal rating:
Characteristic:
6.3 A
slow blow
Supply voltage
characteristic value G and M
Nominal rating:
Characteristic:
2.5 A
slow blow
Connection type for
power unit
characteristic value C
and G
2-pin spring-loaded terminal for copper wire with cross-section
AWG20 ... AWG12 (0.5 mm² ... 3.0 mm²) and stripping length 12 mm
Connection type for
power supply units
characteristic value L
and M
2-pin terminal block
