Hirschmann MACH1000 Series User Manual

42
Installation MACH1000
Release 06 03/2021
Figure 14: Connecting the supply voltage via the 3-pin spring-loaded terminal
1 - Field connection terminal for supply voltage
2 - Terminal lock
 Connect the wires according to the pin assignment on the device with the
clamps.
321
-/N
+/L
1
2
