(4pcs), Collar Sheath (4pcs), ф6 Cushion (4pcs) and
Hexagon Flange Bolt M6*20 (4pcs).
2.Connect the water tank bracket combination on the frame with
2pieces of Hexagon Flange BoltsM6×12..
3..Connect the water tankslanting support combination on
the frame with 2pieces of Hexagon Flange BoltsM6.
4. Use Hoops (4pcs) and Rubber Pipes (2pcs) to connect
Water Cooling System with Engine.
Pours the high quality refrigerating fluid into the water tank
after install.
Recommended antifreeze:
High quality ethylene glycol antifreeze containing
corrosion inhibitors for aluminum engines.
Antifreeze and water mixing ratio:
1:1
Total amount:
1.8L(1.58 lmp qt,1.90 US qt)
Coolant reservoir capacity
(up to the maximum level mark):
0.3L(0.26lmp qt,0.32 US qt)
