1Flange boltM8×16
2. Flange boltM8×20
4.1.1.6 Inspect and maintain the steering drive axle
1、Inspect the cross gimbal turn agility with no stagnation.
If does,dismantle and checke the cross axis, needle
bearing,and the bearing hole on the cross gimbal fork
whether have wear and corrosion,to instead the parts
basesd on the checke.(Attached figure4-1-9)
Attached figure4-1-9
Attention Install the cross gimbal,daub the
lithium grease on the surface of the bearing.
2 、 Inspect the transmission shaft whether have crack and
distortion.If it does,instead the parts.
4.1.1.7 Dismantle the direction machine part
1、Loose the four piece of nolt,dismantle the direction
the cross gimbal
