7.。Fix Disk Brake Plate onto the Bottom Seat with six pieces
of M8 Bolts.
Attention,Grease the bolt with thread glue when
fastening
Fastening Torque of bolt: 22 N.m -28N.m
8.Mount the Bottom Seat of disk brake plate and rear
middle transmission shaft and rear bridge onto the
rear bridge.(AttachedFigure4-2-12)
9. Mount the Disk Brake Clip onto rear bridge with two pieces
of Mbolt.
Fastening Torque,18 N.m -12 N.m
10 、 Sequently fixe the F/R three contacts of front fuel
pipe,F/R fuel pipe.
4.2.3 Dismantle,inspect,maintain and instead the Parking
system
4.2.3.1 Dismantle the parking system
1、Take down the central lid(AttachedFigure4-2-21)
