5.
Conical NutM10
6.
Front wheel Hub
4.Fix the Plate Clip onto Front Turning Joint with four pieces
of M10×22 Bolts.
Fastening Torque: 18 N.m --22N.m
5、Assemble Front Wheel Components onto Front Wheel Hub with
four piecesof GB/T802M10 Conical
Nuts.(AttachedFigure4-2-20)
Fastening Torque of Conical Nut:50 N.m -55N.m
6.Fix Front Disk Brake Pump onto the frame with two pieces of
M M10×55 bolts.
Fastening Torque of the bolt ,40N.m
Attention:Do not operate the vehicle immediately after
assembling the brake system. Please apply the Brake
Lever several times to fully engage the Disk Brake Plate
and have the Brake Fluid circulating before riding the
vehicle.
