71
Attention: grease the bolt with thread glue when
fastening.
Fastening Torque of the Bolt: 22 N.m -28N.m
3、Fix the Front wheel Hub onto the Front Wheel Shaft
with gasket,open-groove nuts and cotter pins.
(AttachedFigure 4-2-20)
Fastening Torque of the open-groove nut
,50 N.m -60N.m
AttachedFigure 4-2-20
1. Front Wheel Shaft
2. gasket
3. open-groove nut
4.
cotter pin3.2×32
