English I
7. Whenreplacing the saw blade, alwaysconfirm that the rpm rating
ofthe new blade iscorrect for useon this tool.
8. Alwaysshut offthe powerandwait for the sawbladeto completely
stop rotating beforedoing any maintenanceor adjustments.
9. Always clamp or otherwise securethe workpiece to the fence;
otherwise the workpiecemight bethrust from the table and cause
bodily harm.
10. During miter or bevel cutting, always wait for the rotation of the
bladeto stopcompletely before lifting the saw blade.
11. Always makea trial run first before attempting anynew useof the
saw.
12. Always handle the saw blade with care when dismounting and
mounting it.
13. Always confirm that the workpiece isfree of nails or other foreign
objectsbefore beginning a cut.
14. Always keepyour handsout of the path of the saw blade.
15. Always confirm that the lower guard is in the proper placebefore
usingthe saw.
16. Inspectthe tool power cords periodically.
17. Alwaysconfirm thatthe properlengthsandtypesof extensioncords
are being utilized, if necessary,before startingthe tool.
18. Alwaysconfirm thatthe motor airvents arefully openbeforeusing
the tool.
19. Alwayswait until the motorhasreachedfull speed beforestarting a
cut.
20. Always keepthe handlesdry, cleanandfree of oil and grease.Hold
the tool firmly when in use.
11. Alwaysuseoutboard standsto provide supportfor longworkpieces
that overhangthe table of the compound miter saw.
22. Alwaysoperatethetool afterensuringtheworkpieceisfixedproperly
with a viseassembly.
23. The operating instructions provided with the tool shall direct the
user to securethe tool to supporting structure if, during normal
operation, there is a tendencyfor thetool to tip over,slide, or walk
onthe supporting surface.
DON'Ts
NEVER VIOLATE THE FOLLOWING RULES TO ASSURE
SAFE USE OF THIS TOOL:
1. Never operatethe POWERTOOL unlessyou fully understandthe
operating instructions contained in this Manual.
2. Neverleavethe POWERTOOLunattendedwithout first unplugging
the power cord.
3. Neveroperatethe POWERTOOLwhen you aretired, after you have
takenanymedications,or haveconsumedanyalcoholic beverages.
4. Never use the POWERTOOLfor applications not specified in the
instruction manual.
5. Never operatethe tool while wearing loose clothing, a necktieor
jewelry, or while your hair is uncovered,to protectagainst getting
caughtin the movingmachinery.
6. Neverreacharoundthe saw blade.
7. Nevertouch anymoving parts,includingthe blade,while the saw is
in use.
8. Never remove anysafety devicesor blade guards; useof the tool
without themwould be hazardous.
9. Never lockthe lower guard;always confirm that it slides smoothly
beforeusing the tool.
10. Neverdamagethe power cord of the tool.
11. Neverattemptto movea plugged-inPOWERTOOLwhile your finger
is onthe starting switch.
12. Neverusethe POWERTOOLif thestarting switch doesnot turn on
and off properly.
13. Never usethe POWERTOOLif the plastic housingor the handle is
crackedor deformed.
14. Never use the POWERTOOL near flammable liquids or gases
becausesparkingcancauseanexplosion.
15. Never clean plasticcomponentswith solvents becausethe plastic
may dissolve.
16. Neveroperatethe saw unlessall the lower guardsare in place.
17. Neverraisethe saw bladefrom theworkpieceuntil it hasfirst come
to a completestop.
18. Whenslidecutting, neverpull the handletoward the operator,since
this couldcausethe sawbladeto kickupfrom theworkpiece.Always
pushthe handleawayfrom theoperator in asingle,smooth motion.
19. Neverplaceyour limbs insideofthe line nexttowarning sign "0"
while the tool is being operated. This may cause hazardous
conditions.
20. Neveruseabrasivetype bladeson this saw.
21. Neverexposeto rain or usein damplocations.
22. Nevercut ferrous metalsor masonry.
/k WARNING
FOR YOUR OWN SAFETY READ THIS INSTRUCTION
MANUAL BEFORE OPERATING THE COMPOUND
MITER SAW
1. Always wear eyeprotectionwhen using the compound miter saw.
2. Always keephands out of the path of the saw blade.
3. Neveroperatethe saw without the guards in place.
4. Never perform any freehandoperation with the compound miter
saw.
5. Neverreacharound thesaw blade.
6. Always turn offtool and wait for saw bladeto stop before moving
workpieceor changing settings.
7. Always disconnectpowerbefore changing blade or servicing.
8. Saw blade diameteris 10" (255mm).
9. No load speedis 5000/min.
10. To reducethe risk of injury, return carriageto the full rear position
after eachcrosscutoperation.
REPLACEMENT PARTS
Whenservicing useonly identical replacementparts.
Repairsshould beconductedonlyby a Hitachiauthorizedservicecenter.
USE PROPER EXTENSION CORD
Make sure your extension cord is in good condition. When using an extension cord, be sureto use one heavy enough to carry the current your
productwill draw.An undersizedcordwill causeadrop in line voltage resulting in lossof power and overheating.Tableshowsthe correctsizeto use
dependingon cord length and nameplateampererating. If in doubt, usethe next heaviergage.Thesmallerthe gagenumber, the heavierthe cord.
MINIMUM GAGE FOR CORD SETS
Total Length of Cord in Feet (Meter)
O- 25 26- 50 51 - 1OO 101 - 150
(O- 7.6) (7.9 - 15.2) (15.5 - 30.5) (30.8 - 45.7)
Ampere Rating AWG
More Not More
Than Than
0-6 18 16 16 14
6-10 18 16 14 12
10-12 16 16 14 12
12 - 16 14 12 Not Recommended
/_k WARNING:
Avoidelectricalshockhazard,Neverusethistoolwith adamagedor frayedelectricalcordorextensioncord,
Inspectallelectricalcordsregularly,Neveruseinor nearwaterorinanyenvironmentwhereelectricshockis possible,
DOUBLE INSULATION FOR SAFER OPERATION
To ensure safer operation of this power tool, HITACHIhas adopted a double insulation design. "Double insulation" meansthat two physically
separatedinsulationsystems havebeen usedto insulatethe electrically conductivematerials connectedto the powersupply from the outer frame
handled by the operator.Therefore,eitherthe symbol "rs]" or the words and "Double insulation" appearonthe powertool or on the nameplate.
Although this system hasno external grounding, you must still follow the normal electrical safety precautions given in this Instruction Manual,
including not usingthe power tool inwet environments.
4
