I English
6mm Wing bolt
Steel (Optional accessory)
Holder
square X
, (Optional _'_:_-_-
accessory) __i
6mm Wing
nut (Optional
accessory) Height adjustment Base surface
bolt 6mm (Optional
accessory)
Fig.9
Stopper for precision cutting ... (Stopper and holder are optional
accessory)
Thestopper facilitatescontinuousprecisioncutting in lengthsof 11"
to 17-3/4"(280mmto 450mm).
To installthe stopper,attachit tothe holderwith the 6ramwing bolt
asshown in Fig.10.
Stopper
Workpiece (Optional accessory)
Holder
(Optional accessory)
./K CAUTION:
I
LASERRADIATION-DONOT
_ TAREINTOBEAM
MaximumOutput:<lmW,
Wavelength:4OO~7OOnm,
LaserMedium:LaserDiode
CLASSITLASERPRODUCT.
Complieswith21CFR,
Chaptert, SubchapterJ.
Laserradiationon worktable.
_DONOT STAREINTOBEAM.
Fig.12
Move
6mm Wing nut
(Optional accessory)
6mm Wing bolt Height adjustment bolt 6mm
(Optional accessory) (Optional accessory)
Fig.10
Confirmation for useof subfence (B) ...(Standardaccessory)
Z_ WARNING:
Inthecaseof left bevelcutting,rotatethe subfence(B).Supposing
itisnotabletorotateit,Itwillcontactthebladeorsomepartofthe
tool,causinginseriousinjurytooperator.
Sub fence (B)
Fence (B) _!_.L_"- ".........
Fig.11
6. Position adjustmentof laserline (OnlyModel C10FCH2)
,/_ WARNING:
* Make surebeforepluggingthe power pluginto the receptacle
thatthe mainbodyandthelasermarkerareturnedoff.
* Exerciseutmostcautionin handlinga switchtrigger for the
positionadjustmentofthelaserline,asthepowerplugisplugged
intothereceptacleduringoperation.
If the switchtriggeris pulledinadvertently,the sawbladecan
rotateandresultinunexpectedaccidents.
* Donot removethe lasermarkerto beusedfor otherpurposes.
( • AVOIDEXPOSURE'_
/ ^ T Laserradiation|
I /_' is emitted from I
Fig.13
* Laserradiation-- Donot stareintobeam.
* Laserradiationonworktable.Do not stareintobeam.
Ifyoureye isexposeddirectlyto thelaserbeam,itcanbe hurt.
* Donot dismantleit.
* Donotgivestrongimpacttothelasermarker(mainbodyoftool);
otherwise,thepositionofalaserlinecangooutoforder,resulting
inthedamageof thelasermarkeraswellasa shortenedservice
life.
* Keep the laser marker lit only during a cutting operation.
Prolongedlightingof the lasermarkercanresultina shortened
servicelife.
* Use of controlsor adjustmentsor performanceof procedures
other than those specifiedherein may result in hazardous
radiationexposure.
NOTE:
Performcuttingby overlappingtheinklinewiththe laserline.
Whentheink lineandthe laserlineareoverlapped,the strength
andweaknessof lightwill change,resultingin astablecutting
operationbecauseyoucaneasilydiscerntheconformityoflines.
Thisensurestheminimumcuttingerrors.
Inoutdoorornear-the-windowoperations,itmaybecomedifficult
to observe the laser line due to the sunlight. Under such
circumstances,moveto a placethat isnot directlyunderthe
sunlightandengageintheoperation.
Donottugonthecordbehindthemotorheadorhookyourfinger,
woodand thelikearoundit; otherwise,the cordmaycomeoff
andthe lasermarkermaynot belit up.
Ink lining can be easily made on this tool to the laser marker.A
switch lights upthe lasermarker.(Fig.14)
Dependingupon your cutting choice, the laser line canbe aligned
with the left sideof the cuttingwidth (sawblade)or the ink line on
the right side.
