Note: You need to perform the wipe procedure on both server modules.
If you can connect to both server modules at the same time, you can
perform the procedure on both server modules concurrently. You do not
need to synchronize the steps between the two modules.
3. Power on the server module to which you connected the keyboard and
monitor.
4. When you see this prompt, press F11:
You have approximately one minute to do this. If the prompt disappears
before you press F11, press Ctrl+Alt+Delete to reboot the server
module.
5. In the Please select boot device menu that appears, arrow down to
FLASH Drive SM_USB20 1100. Then press Enter.
Note: The Please select boot device menu may have an option for the
flash drive prefixed with UEFI. Do not select that option.
78
Chapter 4: Refurbishing an HCP S30 Node
HCP S Series Node Refurbishment
Step 11: Wipe the drives
