5-20 ●Transmission Sequences
(2)Specify Horizontal/Vertical directions and move
● Specify the number of dots for moving and the print item will be moved.
● Horizontal and Vertical move
ESC2 Header 24H
Classification
41H
Item
number
Item number
(1 to 100)
(Contd.)
Vertical
sign
10s place Unit place
Vertical (Y) direction
(-29 to +29)
Horizontal sign/Vertical sign
(Input either one of the two.)
2BH: " ＋ (plus)"
2DH:" － (minus)"
Horizontal
sign
10000s
place
1000s place 100s place 10s place Unit place
Horizontal (X) direction
(-31998 to +31998)
-- Either plus(+) or minus(-) sign to be input for both Horizontal/Vertical directions.
-- In case there will be NO horizontal move, input either "+00000" or "-00000".
-- In case there will be NO vertical move, input either "+00" or "-00".
● Horizontal move
ESC2 Header 24H
Classification
42H
Item
number
Item number
(1 to 100)
(Contd.)
Horizontal sign
(Input either one of the two.)
2BH: " ＋ (plus)"
2DH:" － (minus)"
Horizontal
sign
10000s
place
1000s place 100s place 10s place Unit place
Horizontal (X) direction
(-31998 to +31998)
-- Either plus(+) or minus(-) sign to be input for Horizontal direction.
-- In case there will be NO horizontal move, input either "+00000" or "-00000".
● Ve rtic a l move
ESC2 Header 24H
Classification
43H
Item
number
Vertical
sign
10s place Unit place
Item number
(1 to 100)
Vertical (Y) direction
(-29 to +29)
Vert ic al s ig n
(Input either one of the two.)
2BH: " ＋ (plus)"
2DH:" － (minus)"
-- Either plus(+) or minus(-) sign to be input for Vertical direction.
-- In case there will be NO vertical move, input either "+00" or "-00".
(Contd.)
