●Transmission Sequences 5-25
ESC Header 80H Item No. Type Setting value
(1) Initial value, Range, Jump from, Jump to, Reset
Code of type
Initial value Range 1 Range 2 Jump from Jump to Reset
ASCII303132333435
ASCII is hexadecimal number.
Character code of setting value
Mode Alphanumeric User pattern
1-byte mode ASCII ASCII
2-byte mode ASCII 1-byte code
*) When count characters has been divided (e.g., [ CC CC ]), transmit four-digits characters.
ESC Header 81H Item No. Type
100000s
place
10000s place 1000s place 100s place 10s place Units place
(2) Update setting range
Code of type
In progress Unit
ASCII 30 31
ASCII is hexadecimal number.
Update setting range
Set item Update setting range
In progress 000000 to 999998
Unit 000001 to 999999
ESC Header 82H Item No. Type 0/1
(3) Direction, External signal count, Reset signal
Direction (0: up, 1: down)
External signal count (0: Disable, 1: Enable)
Reset signa (0:Signal1, 1:Signal2)
Code of type
Direction External signal count Reset signal
ASCII303132
ASCII is hexadecimal number.
ESC Header 83H Item No. Type 10s place Unit place
(4) Increment
Increment setting range
Set item Increment setting range
Increment 01 to 99
5.3.7-2 Example of calendar conditions transmission
(1) Example of offset
02H 1FH 28H 32H 32H 32H 30H 30H 31H 32H 03H
STXESC2(22Day0012ETX
Calendar
Offset 12 days
block No.
[Existing machine message] Existing machine message can also be used.
Header,
classification
[Transmission results]
Defines offset 12 days for calendar block 2.
