11. 2048-Bits Serial EEPROM – 24LC02
11.1. General Description
The 24LC01/02 is a 1K/2K-bit serial read/write non-volatile memory device using the
CMOS floating gate process. Its 1024/2048 bits of memory are organized into 128/256
words and each word is 8 bits. The device is optimized for use in many industrial and
commercial applications where low power and low voltage operation are essential. Up to
eight HT24LC01/02 devices may be connected to the same two-wire bus. The
HT24LC01/02 is guaranteed for 1M erase/write cycles and 40-year data retention.
11.2. Features
x Operating voltage: 2.4V~5.5V
x Low power consumption
x Operation: 5mA max.
x Standby: 5mA max.
x Internal organization
x 1K (HT24LC01):128´8
x 2K (HT24LC02): 256´8
x 2-wire serial interface
x Write cycle time: 5ms max.
x Automatic erase-before-write operation
x Partial page write allowed
x 8-byte Page write modes
x Write operation with built-in timer
x Hardware controlled write protection
