SOFTWARE FEATURES
x Input Data Format
x 1-byte Command code
x Block Lock protection
x The BP0~BP1 status bit defines the size of the area to be software protected
against Program and Erase instructions.
x Auto Erase and Auto Program Algorithm
x Automatically erases and verifies data at selected sector
x Automatically programs and verifies data at selected page by an internal
algorithm that automatically times the program pulse widths (Any page to be
programed should have page in the erased state first)
x Status Register Feature
x Electronic Identification
x JEDEC 2-byte Device ID
x RES command, 1-byte Device ID
HARDWARE FEATURES
x SCLK Input
x Serial clock input
x SI Input
x Serial Data Input
x SO Output
x Serial Data Output
x WP# pin
x Hardware write protection
x HOLD# pin pause the chip without diselecting the chip
x PACKAGE
x 8-pin SOP (150mil)
x All Pb-free devices are RoHS Compliant
13.3 Absolute Maximum Ratings
