The control input tolerates voltages up to 5.5V, independent of the VCC operating
range.
15.13.2. Features
x Useful in both analog and digital applications
x Space-saving, SC70 6-lead surface mount package
x Ultra-small, MicroPak™ Pb-free leadless package
x /RZ2Q5HVLVWDQFHȍRQW\SLFDODW99&&
x Broad VCC operating range: 1.65V to 5.5V
x Rail-to-rail signal handling
x Power-down, high-impedance control input
x Over-voltage tolerance of control input to 7.0V
x Break-before-make enable circuitry
x 250 MHz, 3dB bandwidth
15.13.3. Absolute Maximum Ratings
15.13.4. Pinning
