15
A99UE13-1304
8. LAK2J Series(UL approved only DC IN versions):
8.1 LAK2J can combine uniaxial or bi-axial linear actuators.
8.2 A portable controller is designed in this product driven by two 12VDC lead acid
batteries with 4.5Ah without built-in transformer.
8.3 The EMERGENCY button on a panel can disconnect the function of a controller to
protect customers users.
8.4 Users can directly press the UP on DOWN key on a panel without a key box (The
button can only be use to do the up and down control for the rst axis).
8.5 Over current protection and slow start are provided to avoid misuse.
8.6 A LAKCH-A or LAKCH-B charger is required for charging, but AC-IN type are
charged by connecting to 110V or 220V directly.(For the sake of safety, a controller
can’t be used in charging.).
8.7 In 30 seconds after stopping operation, it will automatically become energy-saving
mode to increase the use time. The low-level buzz and LED power indication are
provided as well.(In AC-IN type, the LED on the control panel are need to feed 110V
or 2200V ).
8.8 Fuse specication：15A/20mm.
8.9 Note: Please charge battery for at least 12 hours before initial use.
9. LAK4 Series:
9.1 LAK4 can combine uniaxial to 3-axial linear actuators.
9.2 The output power of a controller is 72.5VA (The output voltage is 24VDC.).
9.3 LAK4 can combine LAN1 to save the space and be easily installed (Please refer to
the gure below.).
9.4 Fuse specication：2A/20mm(220/230VAC)，
3A/20mm(100/110VAC).
