DeviceNet Network Status LED
DeviceNet Module Status LED
State Summary Description
Solid Green Online and
communicat-
ing
The Anybus-X is on the DeviceNet
network and communicating with at
least 1 device.
Flashing Green Online, no
communica-
tion
The Anybus-X is on the DeviceNet
network and is not currently communi-
cating with any devices.
Solid Red DeviceNet
interface fault
A major fault in the DeviceNet inter-
face has been detected. Possible causes
include Bus-off or duplicate MAC ID.
Flashing Red Connection
time-out
A connection with at least 1 slave
device has timed out.
Red,Green
Alternate Flashing
Self Test A self test of the module is in progress.
Table 10-2 DeviceNet Network Status LED States
State Summary Description
Flashing Green Initializing,
standby, or
not config-
ured
The module is initializing.
The DeviceNet network configuration
has not been configured and is cur-
rently using default values.
Solid Green Normal Normal operation.
Solid Red Unrecover-
able fault
A fault the requires user intervention
has been detected. Correct the problem
and reset the Anybus-X.
Flashing Red Recoverable
fault.
A fault that can be corrected and does
not require a Anybus-X reset has been
detected. This will typically be a con-
figuration error.
Red,Green
Alternate Flashing
Self Test A self test of the module is in progress.
Table 10-3 DeviceNet Module Status LED States
