Status and Diagnostics 10-3
© 2005 HMS Industrial Networks AB7607 User manual
Ethernet Activity LED
The Ethernet Activity LED flashes green as Ethernet packets are received or
transmitted.
Ethernet Link LED
The Ethernet Link LED indicates that the module is connected to an Ethernet net-
work. The LED will display solid green if there is a valid physical link.
Ethernet Module Status LED
State Summary Description
Off No Power Not powered
Solid Green Normal The module is operating correctly.
Flashing Green Standby The module has not been initialized.
Solid Red Unrecover-
able fault
A fault the requires user intervention
has been detected. Correct the problem
and reset the Anybus-X.
Flashing Red Recoverable
fault.
A fault that can be corrected and does
not require a Anybus-X reset has been
detected.
Red,Green
Alternate Flashing
Self Test A self test of the module is in progress.
Table 10-4 Ethernet Module Status LED States
