4040
Stripe Hog Systems
bar. As the operator becomes more experienced,
nozzle selection becomes easier. You can also
contact Hog Technologies Customer Support toll
free at (877) HOG-ROAD for assistance in select-
ing the proper spray bar and nozzle conguration
for your job.
The nozzle should be removed from service
if any of the following are indicated:
• Nozzle is split or damaged
• Nozzle is clogged
• Nozzle water spray is fanned out
• Nozzle’s ability to hold pressure is suspect
• Nozzle’s hex head is worn excessively from
blasting
• Nozzle threads are damaged
When replacing nozzles make sure to check the
ow and pressure rating. Use only nozzles with
a manufacturer’s pressure rating of at least the
UHP pump’s maximum operating pressure. We
recommend that you only use nozzles, high pres-
sure hoses and ttings supplied by Hog Technolo-
gies to ensure the nozzles and other components
are compatible with your ultra high pressure
waterblasting system.
