General Maintenance

ITEM# COMPONENT DESCRIPTION ITEM# COMPONENT DESCRIPTION

1. Vacuum Blower Pulley End Bearings 7. Thru-shaft Motor Bearings

2. Driveshaft Splines & Universal Joints 8. Blast Head Chassis Wheels & Casters

3. Vacuum Door Hinges & Latches 9. All Blast Head Chassis & Hog Arm Safety Pins

4. Ladder & Service Platform Hinges & Safety Pins 10. Debris Tank Tilt Cylinder Bearings

5. Ball Valves 11. Debris Tank Tilt Hinges

6. Silencer Exhaust Flapper Hinges

Stripe Hog Lubrication Chart 1
