Holtek HT66F002 User Manual

Rev. 1.71 110 April 11, 2017 Rev. 1.71 111 April 11, 2017
HT66F002/HT66F0025/HT66F003/HT66F004
Cost-Effective A/D Flash MCU with EEPROM
HT66F002/HT66F0025/HT66F003/HT66F004
Cost-Effective A/D Flash MCU with EEPROM
INTEG Register – HT66F004
Bit 7 6 5 4 3 2 1 0
Name — — — — INT1S1 INT1S0 INT0S1 INT0S0
R/W — — — — R/W R/W R/W R/W
POR — — — — 0 0 0 0
Bit7~4 Unimplemented,readas“0”
Bit3~2 INT1S1, INT1S0:DenesINT1interruptactiveedge
00:DisableInterrupt
01:RisingEdgeInterrupt
10:FallingEdgeInterrupt
11:DualEdgeInterrupt
Bit1~0 INT0S1, INT0S0:DenesINT0interruptactiveedge
00:DisableInterrupt
01:RisingEdgeInterrupt
10:FallingEdgeInterrupt
11:DualEdgeInterrupt
INTC0 Register – HT66F002/HT66F0025/T66F003
Bit 7 6 5 4 3 2 1 0
Name — TB1F TB0F INTF TB1E TB0E INTE EMI
R/W — R/W R/W R/W R/W R/W R/W R/W
POR — 0 0 0 0 0 0 0
B
it7 Unimplemented,readas"0"
Bit6 TB1F :TimeBase1InterruptRequestFlag
0:Norequest
1:Interruptrequest
Bit5 TB0F:TimeBase0InterruptRequestFlag
0:Norequest
1:Interruptrequest
Bit4 INTF:INTInterruptRequestFlag
0:Norequest
1:Interruptrequest
Bit3 TB1E :TimeBase1InterruptControl
0:Disable
1:Enable
Bit2 TB0E:TimeBase0InterruptControl
0:Disable
1:Enable
Bit1 INTE:INTInterruptControl
0:Disable
1:Enable
B
it0 EMI:GlobalInterruptControl
0:Disable
1:Enable
