HT66F002/HT66F0025/HT66F003/HT66F004
Cost-Effective A/D Flash MCU with EEPROM
HT66F002/HT66F0025/HT66F003/HT66F004
Cost-Effective A/D Flash MCU with EEPROM
INTC0 Register – HT66F004
Bit 7 6 5 4 3 2 1 0
Name — TB1F TB0F INT0F TB1E TB0E INT0E EMI
R/W — R/W R/W R/W R/W R/W R/W R/W
POR — 0 0 0 0 0 0 0
Bit7 Unimplemented,readas“0”
Bit6 TB1F:TimeBase1InterruptRequestFlag
0:Norequest
1:Interruptrequest
Bit5 TB0F:TimeBase0InterruptRequestFlag
0:Norequest
1:Interruptrequest
Bit4 INT0F:INT0InterruptRequestFlag
0:Norequest
1:Interruptrequest
Bit3 TB1E :TimeBase1InterruptControl
0:Disable
1:Enable
Bit2 TB0E:TimeBase0InterruptControl
0:Disable
1:Enable
Bit1 INT0E:INT0InterruptControl
0:Disable
1:Enable
Bit0 EMI:GlobalInterruptControl
0:Disable
1:Enable
INTC1 Register – HT66F002/HT66F0025
Bit 7 6 5 4 3 2 1 0
Name — ADF DEF MF0F — ADE DEE MF0E
R/W — R/W R/W R/W — R/W R/W R/W
POR — 0 0 0 — 0 0 0
B
it7 Unimplemented,readas"0"
Bit6 ADF:A/DConverterInterruptRequestFlag
0:Norequest
1:Interruptrequest
Bit5 DEF:DataEEPROMInterruptRequestFlag
0:Norequest
1:Interruptrequest
Bit4 MF0F:Multi-function0InterruptRequestFlag
0:Norequest
1:Interruptrequest
Bit3 Unimplemented,readas"0"
Bit2 ADE:A/DConverterInterruptControl
0:Disable
1:Enable
Bit1 DEE:DataEEPROMInterruptControl
0:Disable
1:Enable
Bit0 MF0E:Multi-function0InterruptControl
0:Disable
1:Enable
